Purple Horn 0.3mm Laser Beam Welding Equipment , Portable Laser Welder For Battery
| Place of Origin | China |
|---|---|
| Brand Name | Purple Horn |
| Certification | CE FDA Certification |
| Model Number | ML-WG-ZD-4D-WXXX |
| Minimum Order Quantity | 1 Set |
| Price | Negotiable |
| Packaging Details | Plywood Box |
| Delivery Time | 7~10 Work Day |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 600 Set/Month |
Product Details
| Brand | Purple Horn | Warranty | 1Year , 2 Year |
|---|---|---|---|
| Laser Source Brand | IPG/MAX/RECI | Transportation | Ocean Freight , Air Transportation , Railway Transportation |
| Deliver Method | FOB , CFR | Application | Electrical Accessories Processing , Handicraft Processing , Hardware Processing , Mold Processing |
| Keywords | Damage Free Marking | ||
| Highlight | 0.3mm laser beam welding equipment,Purple Horn laser beam welding equipment,Purple Horn portable laser welder |
||
Product Description
Optical fiber laser welding machine is a kind of laser welding equipment which can couple high energy laser beam into optical fiber, and after long-distance transmission, collimate parallel light through collimating mirror and focus on the workpiece, with a simple universal instrument, the flexible transmission non-contact welding can be carried out for welding large-scale die and precise parts which are difficult to be approached.
- It is suitable for spot welding of all kinds of complicated welds and devices. It adopts imported ceramic focusing cavity, which is more corrosion-resistant, high temperature-resistant and longer service life Ability to work 24 hours a day, the stable performance of the machine is suitable for materials and applications in the fields of optical communication devices, medical treatment, batteries, optical fiber couplers, picture tube electron guns, metal parts, precision parts, all kinds of molds, automobile steel sheet and other welding industries
| Model | ML-WG-ZD-4D-WXXX |
| Laser wavelength |
1064nm |
| Laser material |
Nd:YAG |
| Pulse width |
0.1—20ms |
| Pulse frequency |
≤100Hz |
| Fiber core diameter |
0.3mm,0.4mm,0.6mm |
| Minimum spot diameter |
0.4mm |
| Rated laser power |
200W,400W |
| Maximum power of the machine |
16kw |
|
Cooling system |
Water Cooling |
| Electricity demand |
380V |
| Contour dimension |
1200mm*600mm*1100mm |
| weight |
300kg |
FAQ
1. How is the payment?
30% deposit before production and the balance 70% before shipment
2. How is the delivery and shipment?
Ship in 7 days after 100% payment
Plywood box packaging
3. How will you guarantee aftersales services?
We offer two warranty for laser source, one year for whole machine and lifetime maintenance services.
Engineers available to service machinery overseas
Free technical training in our factory
Free sample can be sent to you
Professional technical team 24 hours online
4. How about your presales service?
Speeding offer within 8 hours quick response and free consulting
Free sample marking or testing is available
Progressing solution design to all clients, including distributors and end users
