High Precision CE Certified 200W Laser Welding Solution Automatic

  • High Precision CE Certified 200W Laser Welding Solution Automatic
  • High Precision CE Certified 200W Laser Welding Solution Automatic
  • High Precision CE Certified 200W Laser Welding Solution Automatic
  • High Precision CE Certified 200W Laser Welding Solution Automatic
Place of Origin CHINA
Brand Name Purple Horn
Certification CE
Model Number ML-WA-W200
Minimum Order Quantity 1 SET
Price USD12,000-20,000
Packaging Details PLYWOOD BOX
Delivery Time 100 SETS PER MONTH
Payment Terms T/T
Product Details
Laser Type Fiber Laser Rated Power 200W
Max. Power 240W Laser Wavelength 1064nm
Laser Spot Range 0.2-3.0mm Pulse Width 0.1-20ms
Welding Depth ≤2mm Pulse Frequency ≤100Hz
Total Power 6Kw Control System PC
Positioning CCD, Red Light Working Area 200*200mm-1200*1200mm(Optional)
Highlight

200W Laser Welding Solution

,

CE Laser Welding Solution

,

CE handheld laser welding system
Leave a Message
Product Description



Features



  • Adpots Britain imported dual-lamp focus cavity, corrosion resistance, high-temperature resistance, the cavity service life could reach 8~10 years.
  • High production efficiency, high welding speed, could realize automatic bulk production.
  • The laser head and rout could revolve by 360 degrees, could stretch forward and backward.
  • 2D or 3D worktable, could adjust the welding spot.

Applicable materials and fields

  • Suitable for welding of water boiler, cup, stainless steel bowl
  • Laptop cover, phone battery, door handle, mould, electronic parts, alumnium artware welding
  • The welding graphic available is point, line, round, squre or any plane shape in Autocad.

Model list



No. Name Parameter
1 Model ML-WA-W200 ML-WA-W400
2 Laser type ND: YAG
3 Rated power 200W 400W
4 Max. power 240W 500W
5 Laser wavelength 1064NM
6 Laser spot range 0.2MM-3.0MM (optional)
7 Pulse width 0.1MS-20MS
8 Welding depth ≤2MM ≤3MM
9 Pulse frequency ≤100HZ
10 Total power 6KW 12KW
11 Control system PC
12 Positioning CCD, red light
13 Working area 200x200MM-1200x1200MM (optional)
14 Power supply 380V/3Phase/50Hz/100A
15 Host dimensions 1600x1200x1300MM
16 Cooling system dimensions 1200x300x900MM
