Steel Sheet Metal Aluminium Automatic Welding Soldering Machine For Stainless Steel

Place of Origin China
Brand Name Herolaser
Certification ISO9001, FDA
Model Number ML-WF-ZD-3D-3000
Minimum Order Quantity 1 set
Price Negotiable
Packaging Details Wooden case
Delivery Time 30-45 days
Payment Terms L/C, T/T
Supply Ability 20 sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Dimensions 1600*1400*2000MM Machine Weight 380KG
Laser Power 3000W Average Load Power 10.9KW
Welding Depth 4mm Focal Spot Diameter 0.10mm-0.45 Mm
High Light

3000W Welding Soldering Machine

,

IPG Welding Soldering Machine

,

4mm Automatic Laser Welding Machine

Leave a Message
Product Description



Parameter
Main technical parameters of the equipment
Product Specifications
S/N
Main component name
Parameter
Remark
1
X axis effective stroke
500mm

2
Y axis effective stroke
300mm

3
Z axis effective stroke
300mm

4
Dimensions
1500×1400×1900mm

5
Machine weight
380kg

6
Module operating speed
Y axis:10m/min
X axis:10m/min
Z axis:5m/min

7
repeated positioning accuracy
±0.02mm

8
Rotating table
Circle runout accuracy ≤0.05mm

9
electricity demand
220V/380V

10
Average load power
10.9KW

Equipment configuration list
Configuration Parameter
S/N
Name
Specifications & Models
QTY
Brand
Remark
1
Fixture mounting plate
350mm×450mm
1
Hero Laser Custom

2
Laser
According to sample welding requirements
1
MAX or IPG

3
Motor
servo motor
3
Huichuan

4
Computer
PC/Industrial Computer
1
Advantech

5
Chiller
According to laser power
1
S & A

6
Welding head
According to sample welding requirements
1
Hero Laser

7
CCD Visual observation system
camera
light source
1
Microsan
Basler/LeTV Light Source

8
Z axis module
300mm stroke
1
Hero Laser Custom
X, Y axis screw lead 10mm, Z axis screw lead 5mm; screw accuracy: C7
9
X axis module
500mm stroke
1
Hero Laser Custom
10
Y axis module
300mm stroke
1
Hero Laser Custom
11
Rotating table
Three-jaw rotary chuck
1
Hero Laser Custom

12
Lower cabinet
Sheet metal welding, paint baking
1
Hero Laser Custom




Steel Sheet Metal Aluminium Automatic Welding Soldering Machine For Stainless Steel 0

Products Description

1. High speed, large depth and small deformation.



2. It can be welded at room temperature or under special conditions, and the welding equipment is simple. For example, if a laser passes through an electromagnetic field, the beam will not shift; Laser can weld in vacuum, air and some gas environment, and can weld through glass or materials with transparent beam.



3. It can weld refractory materials such as titanium, quartz, etc., and can weld dissimilar materials with good results.



4. After laser focusing, the power density is high. When welding high-power devices, the depth width ratio can reach 5:1, and the maximum can reach 10:1.



5. Micro welding is possible. After focusing, the laser beam can obtain very small light spot, and can be accurately positioned, which can be applied to the assembly welding of micro and small workpieces in mass automatic production. (The minimum facula can reach 0.1mm)



6. It can be used to weld parts that are difficult to access. It is very flexible to perform non-contact remote welding. Especially in recent years, fiber transmission technology has been used in YAG laser processing technology, and the popularity of fiber continuous laser has made laser welding technology more widely promoted and applied, which is more convenient for automatic integration.



7. The laser beam can easily realize the beam splitting according to time and space, and can be processed simultaneously by multiple beams and multiple stations, providing conditions for more precise welding.



Steel Sheet Metal Aluminium Automatic Welding Soldering Machine For Stainless Steel 1
Laser welding machines use high-energy pulsed lasers to weld objects


Herolaser automatic laser welding machine can realize the welding of metal work pieces in straight lines, circles and other arbitrary trajectories, such as phone housing, mobile phone batteries, sensors, medical equipment and other industries.



After the laser beam is focused, the point can be accurately positioned and used for group welding of small and



micro workpieces to achieve mass production.



Steel Sheet Metal Aluminium Automatic Welding Soldering Machine For Stainless Steel 2

Sample Show
Steel Sheet Metal Aluminium Automatic Welding Soldering Machine For Stainless Steel 3

Laser welding is one of the important aspects in the application of laser material processing technology. In the 1970s, it was mainly used for welding thin wall materials and low-speed welding. The welding process was of heat conduction type, that is, laser radiation heated the surface of the workpiece. The surface heat diffused through the heat transfer and guided to the interior. By controlling parameters such as the width, energy, peak power and repetition frequency of the laser pulse, the workpiece was melted to form a specific molten pool. Because of its unique advantages, it has been successfully applied to the precision welding of micro and small parts



Steel Sheet Metal Aluminium Automatic Welding Soldering Machine For Stainless Steel 4 Steel Sheet Metal Aluminium Automatic Welding Soldering Machine For Stainless Steel 5  Steel Sheet Metal Aluminium Automatic Welding Soldering Machine For Stainless Steel 6

Steel Sheet Metal Aluminium Automatic Welding Soldering Machine For Stainless Steel 7

  precision machinery


Steel Sheet Metal Aluminium Automatic Welding Soldering Machine For Stainless Steel 8

  communications


Steel Sheet Metal Aluminium Automatic Welding Soldering Machine For Stainless Steel 9

  handicrafts


Installation Instructions
