Small Integrated CO2 Laser Marking Machine With Galvanometer

Place of Origin China
Brand Name Herolaser
Certification CE, FDA
Model Number ML-MC-KF-00-HW70
Minimum Order Quantity 1 SET
Price Negotiable
Packaging Details 1110mm x 860mm x 1520mm in wood box
Delivery Time 12 days
Payment Terms T/T, Western Union
Supply Ability 600 sets/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Laser Marking Condition New
Cooling Mode Built-In Ail Cooling&Water Cooling Warranty 24months
Product Name Fiber Optical Laser Marking Machine Laser Wavelength 10.6um
Laser Source CO2 Metal Tube,CO2 Glass Tube Applicable Material Non-metal Materials
High Light

Integrated CO2 Laser Marking Machine

,

CO2 Laser Marking Machine With Galvanometer

,

Integrated galvo head co2 laser

Leave a Message
Product Description

Small Integrated Design CO2 Laser Marking Machine with Advanced Galvanometer Marking



Product introdution:



CO2 radio frequency laser is a gas laser with a laser wavelength of 10.64nm, which belongs to the mid-infrared band. CO2 laser has high power and photoelectric conversion rate. Carbon dioxide laser takes carbon dioxide as the working material and fills the discharge tube with auxiliary gases such as carbon dioxide. When a high voltage is applied to the electrode, a glow discharge occurs in the discharge tube, which causes the gas molecules to release the laser. After the laser beam is expanded and focused, it is processed by a deflection scanning mirror.



Characteristics and features:



-Perfect for harsh environments

-Sturdy metal laser tube (above 20000 hours life) Easily replaceable metal laser tube
-Aluminum alloy lifting work table

-Compact and low maintenance

-Easy operation
-Supports a variety of file formats

 (JPG, JPEG, TIF, PLT, DXF, DST, BMP, PNA and others)

-Efficient water cooling system

-The high-speed flow pump offers working stability

-Amazing versatility

-High-precision marking up to 2 mm deep
-Software supports all characters, numbers, codes & graphics



Technical details:



Model ML-MC-KF-00-HW70
Wave Length(um) 9.3/10.2/10.6
Output Power(W) ≥70
Marking Speed ≥7m/s
Marking Area 110mm
Marking Focus 150mm
Marking Font Scribing, dot matrix
Marking Mode Static and dynamic
Online Speed ≤120m/min
Marking Material Label, paper, PET, HDPE, glass, wood, etc
Temperature 5-35℃
Humidity Relative humidity<95%, frost-free
Structure Material High-quality aluminum alloy; stainless steel
Edit Mode Computer software
Communication Interface USB Interface
Power Supply AV220V/50,60HZ
Rated Power 1200W



Application:



Widely used in clothing accessories, leather, food and beverage packaging, electronic components, arts and crafts, glass stone processing and other fields of graphic marking and cutting. It can also be used for marking many non-metallic materials, such as paper packaging, plastic products, labels, leather fabrics, glass ceramics, resin plastics, wood products, PCB board and so on.



Marking samples for reference:

Small Integrated CO2 Laser Marking Machine With Galvanometer 0

FAQ

1. How is the payment?
  • 30% deposit before production and the balance 70% before shipment
2. How is the delivery and shipment?
  • Ship in 7 days after 100% payment;
  • Plywood box packaging
3. How will you guarantee aftersales services?
  • We offer two warranty for laser source, one year for whole machine and lifetime maintenance services.
  • Engineers available to service machinery overseas
  • Free technical training in our factory
  • Free sample can be sent to you
  • Professional technical team 24 hours online
4. How about your presales service?
  • Speeding offer within 8 hours quick response and free consulting.
  • Free sample marking or testing is available
  • Progressing solution design to all clients, including distributors and end users.
